The manual modeling process of preparing geometric data for 3D computer graphics is similar to plastic arts such as sculpting. If, for some reason, we needed the bunny to be looking the left, which we had figured out would require a rotation of 65 degrees, we could easily edit that here by changing the Z rotation.Īll our changes are auto-saved, so just we press Done when finished.The product is called a 3D model while someone who works with 3D models may be referred to as a 3D artist or a 3D modeler.Ī 3D Model can also be displayed as a two-dimensional image through a process called 3D rendering or used in a computer simulation of physical phenomena.ģD Models may be created automatically or manually. Lastly, you can rotate to an exact orientation. We’d end up with a really tall bunny!Īt any point, we can use the Undo function (CTRL+Z, or CMD+Z on a Mac), which will undo our changes, or press Reset to revert the model back to its original scale. If we wanted to stretch our model along just one axis, we can uncheck Uniform Scaling and increase one value.
We can simply edit the Z axis to 75, hit Enter or anywhere else on the screen and the model will scale accordingly. For example, let’s say we need this bunny to be exactly 75 millimeters tall. Next is scaling: not only can you scale using percentages, you can also scale to an exact size in millimeters.
This makes it easier to know exactly what you’re getting. You’ll notice that, as you make changes, you can immediately see them reflected on your model. We could also enter a precise value here if needed. Just press the down arrow on the Z offset. An easy way to do that is to drop the model just slightly below the bed, so the very bottom won’t be printed. We’d be better off creating a flat surface.
For example, you can see that this model is not completely flat on the bottom, which means the first layer may not stick as well. Here is where you can edit the X, Y or Z offsets. To open the Panel, double click the model on the bed or its name in the Model List. While the top four icons on toolbar on the right are great for making quick changes to your model, the Model Settings Panel is better for precise numeric adjustments. Today, we’re looking at Simplif圓D’s Model Settings Panel, which lets you edit multiple aspects of your 3D model, such as position, scaling and rotation.
